3 axle 50000 liters 55000 liters gasoline tank semi trailer tanker
This product is suitable for transporting gasoline, kerosene, diesel, vegetable oil, edible oil, heavy oil, coal tar and non-petroleum products such as alcohol, aldehyde, benzene, ether and other liquid substances. All tank trucks can be designed as chemical trucks and various heating and insulation series tanks. There are multiple wave-proof partitions in the tank. High-pressure gas leak test is used to make the tank have high strength, stable center of gravity, and safe and stable vehicle transportation.
Get A Free Quote NowProduct Parameter
| Material | Stainless steel, aluminum alloy, carbon steel | Wheelbase | 7000mm-8000mm |
| Maximum payload | 90t, customizable | Material | Carbon steel, stainless steel, aluminum alloy |
| Number of axes | 2/3/4 axis | Loading capacity | 45t, customizable |
| Axle Brand | Fuwa/BPW | Tire specifications | 11.00r20 12r22.5 315 385 |
| Suspension | Mechanical suspension or air suspension | Traction pin | 50# or 90# |
| Braking system | Dual Line Air Brake | Support device | JOSTBrand Double Speed |
| color | Customizable | Dimensions | 12550*2540*3945Customized according to actual situation |
| Toolbox | Steel or aluminum | Fire extinguisher | 2set |
| Discharge pipe | 3-inch rubber hose, 6 meters/piece | Production Capacity | 500Set/month |
| Function | Can transport fuel, gasoline, diesel, asphalt, edible oil, chemicals, etc. |
Product Introduction
Oil tank trailers are road vehicles designed for safe and efficient transportation of oil and related liquid substances (such as chemicals, oil, food, etc.). Its unique structure and technical features ensure the safety of liquid material transportation, shorten transportation time and reduce transportation costs. The installation of oil and gas recovery devices can also reduce environmental pollution. We have built-in wave-breaking plates inside the tank body, explosion-proof manhole covers and emergency cut-off devices installed on the body. At the same time, partition boards can also be installed inside the tank body to separate the tank body into multiple small compartments, and each tank compartment can be loaded and unloaded independently.
Product Components
